Marca: Risinglcd
Produtividade: 1250k
Lugar de orixe: Shenzhen
Certificado: CE/ROSH/UL/ISO9001
Shenzhen Risingstar 10,1 polgadas 1000 NIT Panel LCD TFT, módulo LCD orixinal AUO/BOE/Innolux, o enlace da placa base co panel LCD está conectado coa interface do panel a través da fila do panel. Diferentes paneis LCD usan diferentes formularios de interface. RisingStar 10,1 polgadas 1000 NITS TFT Panel LCD é principalmente a interface LVDS.
Pareter
| Size | 10.1inch |
| Panel item | RS101NET-N10 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1280*800 |
| brightness | 350-1000cd/m2 |
| Constrast Ratio | 800:1 |
| Response Time | 14/11ms |
| View angle | 85/85/85/85 |
| View area | 218.96*137.6mm(H*V) |
| Dispaly area | 218.96*137.6mm(H*V) |
| Outline Size | 230.7*152.55*7mm(H*V*D) |
| Signal Type | LVDS |
| Working freqyency | 60Hz |
| Working temperature | -20~70ﾟC |
| Storage Temperature | -25~70ﾟC |
| Display ratio | 16:9 |
| Display color | 16.7m |
| Backlight Voltage | 3.3V |
| Backlight Power Consumption | 6.18w |
| Surface Treatment | Haze |
| Weight | 0.375kgs |
Etiquetas quentes: 10,1 polgadas 1000 NIT Panel LCD TFT, China, fábrica, barato, prezo, personalizado, cotización, ventá orientada a LCD, panel LCD brillante, pantalla LCD de TV exterior, panel LCD de luz solar, taboleiro LCD de alta definición, publicidade dixital exterior, 65inchs Pantalla de visualización LCD
